7. Scroll right.
8. Scroll and select the desired input or output. Figure 390 shows the Auto Operation
category to assign Car to Lobby to an unused input.
9. Scroll right and press Save.
21.2 Removing an Input or Output
The following procedure describes how to remove an input or output.
1. Navigate to MAIN MENU | SETUP | SETUP I/O. See Figure 54.
2. From the SETUP I/O menu, select Setup Inputs for the Input menu or Setup Outputs for
the Output Menu. See Figure 268.
NOTE: The input and output steps are the same.
3. From the SELECT BOARD menu, select which board the input or output is being removed
from. See Figure 269.
4. Scroll and select the input or output to be removed. See Figure 390.
5. Scroll right.
6. Scroll and select the current input or output to unused.
7. Scroll right.
8. Scroll and select the desired category of the input/output to unused.
9. Scroll right and press Save.
21.3 Types of Inputs
The tables below list the definition for the types of inputs per category.
Table 34: Description of Auto Operation Inputs
Input
Description
Active Shooter
Places all cars in a group into Active Shooter Mode
(must be programmed to a shared group input on each
car).
Attd Byp
When active, attendant operation causes the car to
skip past all hall calls between its current position and
current destination.
Attd Down
Sets the next direction the car will try to move in the
down direction when doors are closed on attendant
operation.
Attd On
Puts the car on attendant operation.
Attd Up
Sets the next direction the car will try to move in the
up direction when doors are closed on attendant
operation.
Car To Lobby
Captures car and sends it to the lobby where it will
hold doors open.
Custom Operation
Puts car on custom operation mode.
DISA All HC
Disables all hall calls on the car when active.
