Smartrise C4 User Manual

C4 User Manual
Page 318 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
CPLD Menu
Description
PF STAT
Displays a check performed at the end of runs where
safety critical inputs are toggled to confirm hardware
functionality.
PF CMD
Displays the EB relay commands to the MR board as part
of the preflight process. This field is not used by the CT
and COP boards.
INPUTS
Status of signals read by both the CPLD and the MR, CT,
or COP board.
The table below lists CPLD faults.
Table 55: CPLD Fault
Fault Number
Fault Name
Description
0
NONE
None
MR Board
1
STARTUP MR
MR processor has reset.
2
STARTUP CT
CT processor has reset.
3
STARTUP COP
COP processor has reset.
4
UNINT MOV
Missing a lock and a Gate switch and
falling edge of either door zone signal
detected. This fault is latching until reset. If
the COMM LOSS CT fault is active when
the UNINTENDED MOV fault conditions are
met. Then the UNINTENDED MOV fault
should not be flagged.
5
COMM LOSS CT
Communication with the CT CPLD lost. If
the COMM LOSS CT fault is active when
the UNINTENDED MOV fault conditions are
met. Then the UNINTENDED MOV fault
should not be flagged.
6
COMM LOSS COP
Communication with the COP CPLD lost.
Detected and notified by CT CPLD.
7
120VAC LOSS
120 VAC supply monitoring pin is low.
8
GOV LOSS
GOV input lost. But 120VAC is present. This
fault is latching until reset.
9
CAR BYP SW
Car door bypass switch is on and car is not
on IC or CT inspection.
10
HALL BYP SW
Hall door bypass switch is on and car is not
on in car or car top inspection.
11
SFM LOSS
MR SFM input lost.
12
SFH LOSS
MR SFH input lost.
13
PIT LOSS
MR PIT input lost.
14
BUF LOSS
MR BUF input lost.
15
TFL LOSS
MR TFL input lost.
