The table below lists the Setup – S-Curve and Speeds menu structures.
Table 19: Setup – S-Curve and Speeds Menu Structures
Configure S-Curve parameters
Configure speed parameters
Setup drive related parameters
Set pattern parameters used on normal profile runs. The
normal profile is selected in all automatic operation runs
longer than minimum short profile distance, with
exception of emergency power.
Set pattern parameters used on inspection profile runs
Set pattern parameters used on E-Power profile runs
Set pattern parameters used on short profile runs
The rate of deceleration used during an NTS trip. During
an NTS trip, the drive will ignore the controller's
commanded speed, and both will ramp down their
speeds independently.
Sets the rate of decel from leveling speed
Soft Limit Dist. Up (1 ft)
Distance away from the top terminal floor that car
switches to terminal speed during manual operation
Soft Limit Dist. Dn (1 ft)
Distance away from the bottom terminal floor that car
switches to terminal speed during manual operation
Short Run Min. Dist. (1 ft)
Distance below which the short motion profile is used
instead of the normal motion profile
Distance the car slows down prior to the landing in the
up direction
Distance the car slows down prior to the landing in the
down direction
Maximum distance the car is from landing moving in the
up direction
Maximum distance the car is from landing moving in the
down direction
Sets the max acceleration rate used on normal profile
runs
Sets starting rate of acceleration change on normal
profile runs
Sets the rate of acceleration change when approaching
max speed on normal profile runs
Sets the max deceleration rate used on normal profile
runs
To Next Page
