C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 223
Moves the car up when on landing inspection mode.
Moves the car down when on pit inspection mode.
Moves the car up when on pit inspection mode.
Table 43: Description of Safety Inputs
Puts car on flood operation.
Analog load weigher signal indicating the weight is
above the configured threshold and the car cannot
take additional passengers, car will remove itself from
group (stop taking hall calls).
N/C input signals low oil.
N/C input signals low pressure.
N/C input signals motor overheat.
Analog load weigher signal indicating the weight is
above the configured threshold and the car cannot
move. Car will remain stopped with an overload fault.
Indicates if in car emergency phone has failed.
Resets the emergency phone failure buzzer.
Alternate method of resetting a latched traction loss
fault via moveable input.
N/C input signals cold oil.
21.4 Types of Outputs
The tables below list the definitions for the types of outputs per category.
Table 44: Description of Auto Operation Outputs
Activates when the car is in the acceleration stage of its
run.
Discrete arrival lantern output, set 1.
Discrete arrival lantern output, set 2.
Discrete arrival lantern output, set 3.
Discrete arrival lantern output, set 4.
Discrete arrival lantern output, set 5.
Discrete arrival lantern output, set 1.
Discrete arrival lantern output, set 2.
Discrete arrival lantern output, set 3.
Discrete arrival lantern output, set 4.
Discrete arrival lantern output, set 5.
