C4 User Manual
Page 146 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
3. From the TERMINAL SPEED menu, set the speed of the car during inspection.
Figure 211: TERMINAL SPEED Menu
4. Scroll right and press Save.
13.5 Leveling Speed
The leveling speed is the set speed in automatic operation when leveling to a floor during
leveling distance section of the speed curve. If the speed is increased, the car may overshoot
the landing. If the speed is decreased, the car would decelerate directly to the floor.
The adjustment range is from 1-20 fpm.
• Default =5 fpm
• Units of Measure = fpm
The following procedure describes how to set the leveling speed.
1. Navigate to MAIN MENU | SETUP | SPEEDS. See Figure 55.
2. From the SPEEDS menu, scroll and select Leveling Speed.
Figure 212: SPEEDS Menu – Leveling Speed
3. From the LEVELING SPEED menu, set the speed when leveling a car to a floor.
Figure 213: LEVELING SPEED Menu
4. Scroll right and press Save.
