C4 User Manual
Page 300 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
3. From the PIT SMOKE menu, scroll and select Main or Alt.
Figure 588: PIT SMOKE Menu – Main or Alt
4. From the PIT: USE ALT FLOOR menu, scroll and select if the main or alternate floor is
used.
Figure 589: PIT: USE ALT FLOOR Menu
5. Scroll right and press Save.
33.3.8.2 Flash Fire Hat
If the fire flash hat been enabled during PIT smoke, a fire hat symbol on the panel flashes when
smoke has been detected.
The following procedure describes how to enable the flash fire hat.
1. Navigate to MAIN MENU | SETUP | FIRE. See Figure 57.
2. From the FIRE SERVICE menu, scroll and select PIT Smoke. See Figure 587.
3. From the PIT SMOKE menu, scroll and select Flash Fire Hat.
Figure 590: PIT SMOKE Menu – Flash Fire Hat
4. From the PIT: FLASH FIRE HAT menu, scroll and select On.
Figure 591: PIT: FLASH FIRE HAT Menu
5. Scroll right and press Save.
