Triggers when the car is in normal operation and is
parked.
Activates when the car is in Sabbath operation.
Activates when the car is in an automatic mode of
operation and the load weigher has flagged an
overloaded state.
Triggers when the car is moving down.
Triggers when the car is moving up.
Table 45: Description of Car Call (Front and Rear) Outputs
Table 46: Description of Controller Outputs
Lamp output when auto rescue is active.
Output signaling car is on battery power.
Activates when the primary brake pick switch signals
the brake is open.
Activates when the secondary brake pick switch signals
the brake is open.
AC primary brake pick output.
AC secondary brake pick output.
CEDES Maintenance Fan output. Blows air at Cedes tape
when in motion to clear accumulated dust.
Output to the Delta relay which picks the Run Contactor
in a Wye Delta starter configuration.
Triggers prerun energizing of the DSD DC drive.
Turns on car light and fan hardware.
Fan output that will remain active for an adjustable
period of time after each run.
Enables recommended travel direction of Magnetek
drives.
Triggers a reset of an active regen fault.
Triggers manual rescue in event of power loss.
Cycle power to a faulted soft starter.
Signal to start pump motor.
Start pump motor (secondary soft starter).
Triggers the high speed valve in the down direction.
Triggers the high speed valve in the up direction.
