3 Menu Structure
The following figures display the menu options for the C4 Traction Controller.
3.1 Status
Status
Faults
Alarms
Setup
Debug
About
Inspection
Locks
Hoistway Access
Safety Zones
Relays
Doors
Contactors
Auto Operation
Fire/Earthquake
E-Power
Miscellaneous
Controller
Safety Operations
Inputs
Outputs
Brake Status
EBrake Status
Expansion Status
Riser Board Status
Hall Board Status
Hall Lantern Status
Hall Security Status
Hall Call Status
DAD Status
Clock
CPLD Status
Load Weigher Status
E-Power Status
EMS Status
Virtual Inputs
DIP Status
Door Status (F)
Door Status (R)
Auto Operation
Front Doors
Rear Doors
Fire EQ
E-Power
Inspection
Controller
Safety
CCL Front
CCL Rear
MAIN MENU
Expansion 1-8
Expansion 9-16
Expansion 17-24
Expansion 25-32
Expansion 33-40
Expansion 41-48
Expansion 49-56
Figure 30: Status – Inputs, Outputs, and Expansion Status Menus
