C4 User Manual
Page 144 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
13.2 Access Speed
Access speed is the set speed of the elevator during hoistway access. An overspeed fault occurs
if the speed feedback is higher than 150 fpm. If the speed is increased, the car travels faster. If
the speed is decreased, car runs slower.
The adjustment range is from 0-150 fpm.
• Default = 20 fpm
• Units of Measure = fpm
The following procedure describes how to set the access speed.
1. Navigate to MAIN MENU | SETUP | SPEEDS. See Figure 55.
2. From the SPEEDS menu, scroll and select Access Speed.
Figure 206: SPEEDS Menu – Access Speed
3. From the ACCESS SPEED menu, set the access speed.
Figure 207: ACCESS SPEED Menu
4. Scroll right and press Save.
13.3 E-Power Speed
E-Power speed is the speed of the car during emergency power operation. If the speed is
increased, the car will run faster during emergency power operation. A generator might not be
able to handle higher speeds and slower speeds might be required. If decreased, the car runs
slower. This speed cannot be set higher than contract speed.
The adjustment range is from 0-1200 (or contract speed) fpm.
• Default = 10 fpm
• Units of Measure = fpm
The following procedure describes how to set the speed for emergency power operation.
1. Navigate to MAIN MENU | SETUP | SPEEDS. See Figure 55.
