Page 54 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
The table below lists the Setup –Hoistway Access, Fire, and Earthquake menu structures.
Table 21: Setup –Hoistway Access, Fire, and Earthquake Menu Structures
Menu
Description
Setup
Hoistway Access
Hoistway access setup menu
Fire
Fire operation setup menu
Earthquake
Earthquake operation setup menu
Hoistway Access
Allowed Distance (Top) (1 ft)
Sets the distance below the top hoistway access floor
that the car is allowed to move while in top hoistway
access
Allowed Distance (Bottom) (1 ft)
Sets the distance above the bottom hoistway access
floor that the car is allowed to move while in bottom
hoistway access.
Top Floor
Sets the top hoistway access floor. This value is zero
based, so the bottom most floor is zero. This value's
upper bound is the configured number of floors.
Bottom Floor
Sets the bottom hoistway access floor. This value is zero
based, so the bottom most floor is zero.
Top Opening
When nonzero, configures the top hoistway access to
use the rear opening
Bottom Opening
When nonzero, configures the bottom hoistway access
to use the rear opening
HA Slide Distance
Sets the distance the car is from top/bottom door zone
Fire
Main Recall
Sets the main recall floor
Alt Recall
Sets the designated alternate recall floor
Main Smoke
Main smoke options
Alt Smoke
Alternate smoke options
Hoistway Smoke
Hoistway smoke options
MR Smoke
Machine room smoke options
Recall Key
Key to recall to service floor
PIT Smoke
Pit smoke options
Alt Machine Room
Secondary machine room smoke
Advance Configs
Additional fire features
Main Recall
Floor
Sets the main fire recall floor This value is zero based, so
the bottom most floor is zero
Opening
Sets the main recall opening as front or rear
Alt Recall
Floor
Sets the alternate fire recall floor This value is zero
based, so the bottom most floor is zero
