C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 173
3. From the HALL DWELL TIMER menu, set the time the doors stay open.
Figure 295: HALL DWELL TIMER Menu
4. Scroll right and press Save.
16.4 ADA Dwell Timer
The America’s with Disabilities Act (ADA) timer is the time the doors stay open when answering
calls from disabled passengers.
The following procedure describes how to set the ADA dwell timer.
1. Navigate to MAIN MENU | SETUP | DOOR SETUP. See Figure 55.
2. From the DOORS menu, scroll and select ADA Dwell Timer.
Figure 296: DOORS Menu – ADA Dwell Timer
3. From the ADA DWELL TIMER menu, set the time the doors stay open.
Figure 297: ADA DWELL TIMER Menu
4. Scroll right and press Save.
16.5 Hold Dwell Timer
The hold dwell timer is the time the doors stay open after a hold door button has been
requested.
The following procedures describe how to set the hold dwell timer.
1. Navigate to MAIN MENU | SETUP | DOOR SETUP. See Figure 55.
