Xerox WorkCentre 5225 Service Manual

February, 2008
6-8
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
IOT NVM List Chain 740-xxx ESS IF
Chain 740-xxx Billing
Table 1 Chain 740-xxx ESSIF
Chain-
Link
Name Default Range 1 Count Remarks
740-001 Check System Data Set up 0 0~99 - Controller will write in the optional value when System Data setting is completed.
740-007 MCU VERSION - 0~1 - Not available
740-008 MCU Release Number - 0~99 - Not available
740-009 MCU Patch Level - 0~99 - Not available
740-010 DM ROM Version - 0~99 - Not available
740-011 DM ROM Release Number - 0~99 - Not available
740-012 Exit Version - 0~99 - Not available
740-013 Exit Release Number - 0~99 - Not available
740-022 The Area 1 that Controller is free to use 0 0~99 1 Not available
740-023 The Area 2 that Controller is free to use 0 0~99 1 Not available
740-024 The Area 3 that Controller is free to use 0 0~99 1 Not available
740-025 The Area 4 that Controller is free to use 0 0~99 1 Not available
740-026 The Area 5 that Controller is free to use 0 0~99 1 Not available
740-027 The Area 6 that Controller is free to use 0 0~99 1 Not available
740-028 The Area 7 that Controller is free to use 0 0~99 1 Not available
740-029 The Area 8 that Controller is free to use 0 0~99 1 Not available
740-030 The Area 9 that Controller is free to use 0 0~99 1 Not available
740-031 The Area 10 that Controller is free to use 0 0~99 1 Not available
740-062 Firmware Download Status 1 0~254 For the firmware downloaded by PC-TOOL
740-082 Finisher Version major - 0~99 - Not available
740-083 Finisher Version minor - 0~99 - Not available
740-084 Finisher Patch Level - 0~99 - Not available
740-085 HCF Version major - 0~99 - Not available
740-086 HCF Version minor - 0~99 - Not available
740-087 HCF Patch Level - 0~99 - Not available
740-088 TM-Version - 0~99 - Not available
740-089 TM-Release Number - 0~99 - Not available
Table 2 Billing
Chain-
Link
Name Default Range 1 Count Remarks
740-563 Tray Feed Capacity MAX Over 0 0~1 1 Displays whether the number of feeds exceeds 4,000,000. 0: No, 1: Yes
740-564 IOT Starting Number MAX Over 0 0~1 1 Displays whether the IOT Starting Number NVM was written more than 1,000,000 times.
0: No, 1: Yes
740-565 Billing Counter MAX Over 0 0~1 1 Displays whether the Billing Counter Number NVM was written more than 5,000,000
times. 0: No, 1: Yes
