Xerox WorkCentre 5225 Service Manual

February, 2008
2-351
WorkCentre 5225, 5230
024-947, 024-948
Status Indicator Raps
Launch Version
024-947 Tray 2 Out Of Place RAP
The Tray 2 Paper Size Switch detected no tray.
Initial Actions
• Refer to BSD 7.2.
• Reload the tray correctly.
• Check the operation of the tray actuator.
Procedure
Remove Trays 1 and 2. Replace Tray 1 with Tray 2. [024-947] occurs.
YN
Replace the faulty part of the Tray 2 Actuator.
Check the installation of the Tray 2 Paper Size Switch. The Tray 2 Paper Size Switch is
installed correctly.
YN
Install the Tray 2 Paper Size Switch correctly.
Go to the BSD 7.2 Tray 2 Paper Size Sensing and check the connectors.
024-948 Tray 3 Out Of Place RAP
The Tray 3 Paper Size Switch detected no tray.
Initial Actions
• Refer to BSD 7.3/7.5.
• Reload the tray correctly.
• Check the operation of the tray actuator.
Procedure
[For 2TM]
Remove Trays 3 and 4. Replace Tray 3 with Tray 4. [024-948] occurs.
YN
Replace the faulty part of the Tray 3 Actuator.
Check the installation of the Tray 3 Paper Size Switch. The Tray 3 Paper Size Switch is
installed correctly.
YN
Install the Tray 3 Paper Size Switch correctly.
Go to the BSD 7.3 Tray 3 Paper Size Sensing and check the connectors.
[For TTM]
Check the Tray 3 Actuator. The Tray 3 Actuator is not distorted.
YN
Replace the faulty part of the Tray 3 Actuator.
Check the installation of the Tray 3 Paper Size Switch. The Tray 3 Paper Size Switch is
installed correctly.
YN
Install the Tray 3 Paper Size Switch correctly.
Go to the BSD 7.5 Tray 3 Paper Size Sensing and check the connectors.
