Xerox WorkCentre 5225 Service Manual

February, 2008
2-523
WorkCentre 5225, 5230
071-211, 071-940
Status Indicator Raps
Launch Version
071-211 Tray 1 Broken RAP
BSD-ON:7.1
The Tray 1 Paper Size Switch failed.
Initial Actions
• Reload the tray correctly.
• Check the operation of the tray actuator.
• Power OFF/ON
Procedure
Remove Trays 1 and 2. Replace Tray 1 with Tray 2. [071-211] occurs.
YN
Replace the faulty part of the Tray 1 Actuator.
Check the installation of the Tray 1 Paper Size Switch. The Tray 1 Paper Size Switch is
installed correctly.
YN
Install the Tray 1 Paper Size Switch correctly.
Go to the OF 2 (SIZE SWITCH ASSY RAP).
071-940 Tray 1 Lift Up RAP
BSD-ON:7.1
The Tray 1 Level Sensor does not turn on within the designated time.
Initial Actions
• Remove and reinsert Tray 1
• Realign paper in the tray
• Object other than paper is in the tray
Procedure
1. Tray Level Sensor
2. Drive system from motor to bottom plate
