Xerox WorkCentre 5225 Service Manual

February, 2008
2-677
WorkCentre 5225, 5230
124-335, 124-337
Status Indicator Raps
Launch Version
124-335 Font ROM RAP
BSD-ON:16.1
The Font ROM could not be detected.
Initial Actions
Power Off/On
Procedure
Pull out and insert the Printer PWB (PL 9.2) and the DIMM (PL 9.2) Switch on the power. The
problem persists.
YN
Return to Service Call Procedures.
Check the connection of each ESS PWB connector. The connectors are securely connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the PS DIMM (PL 9.2).
If the problem persists replace the Printer PWB (PL 9.2).
f the problem persists replace the ESS PWB (PL 9.2)
124-337 ESS Standard RAM RAP
BSD-ON:16.1
An error was detected in the ESS Built-In Standard RAM.
Procedure
Reinstall or replace the DDR DIMM (PL 9.2).
If the problem persists replace the ESS PWB (PL 9.2).

Xerox WorkCentre 5225 Specifications

General

Maximum print size	A3 (297 x 420 mm)
Internal memory	No MB
Type	Digital copier
