Xerox WorkCentre 5225 Service Manual

February, 2008
2-526
WorkCentre 5225, 5230
072-105
Launch Version
Status Indicator Raps
072-105 Tray 2 Registration Sensor On JAM RAP
BSD-ON:8.2/8.7
After the Tray 2 Feed Out Sensor turned On, the Registration Sensor did not turn On within the
specified time.
Initial Actions
• Power OFF/ON
Procedure
Check the Transport Roll for wear and paper powder. The Transport Roll is ok.
YN
Replace the Transport Roll.
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Execute Component Control[089-100 Registration Sensor]. Manually activate the actuator of
the Registration Sensor (PL 2.4).
The display changes.
YN
Check the connection of P/J104. P/J104 is connected correctly.
YN
Connect P/J104.
Check the wire between J104 and J403 for an open circuit or a short circuit (BSD 8.7).
The wire between J104 and J403 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P403B-13 (+) and GND (-) (BSD 8.7 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P403B-8 (+) and GND (-) (BSD 8.7 Flag 1).
Actuate the Registration Sensor with paper. The voltage changes.
YN
Replace the Registration Sensor (PL 2.4).
Replace the MCU PWB (PL 9.1).
Execute Component Control[071-015 Takeaway Roll Clutch ON]. The Takeaway Roll Clutch
(PL 2.4) can be heard.
YN
Check the connections of P/J204 and P/J410. P/J204 and P/J410 are connected cor-
rectly.
YN
Connect P/J204 and P/J410.
Measure the resistance of the Takeaway Roll Clutch (PL 2.4) (BSD 8.2 Flag 3). (Between
P204-1 and P204-4)
The resistance is approx. 250~100Ohm.
YN
Replace the Takeaway Roll Clutch (PL 2.4).
Check the wire between J204 and J410 for an open circuit or a short circuit (BSD 8.2 Flag
4).
The wire between J204 and J410 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
A
A
B
B
