Xerox WorkCentre 5225 Service Manual

February, 2008
3-22
WorkCentre 5225, 5230
Launch Version
Image Quality
IQS13 Background Specification
Procedure
Use Side A of the Standard Test Pattern.
Compare images of the test pattern,(Figure 1) made from the
document glass, with the visual scale,82P448.
The background of the images must not be darker than the
reference area “C” (Figure 1).
Figure 1 Test Pattern(j0st3215)
