February, 2008
2-601
WorkCentre 5225, 5230
116-343, 116-346
Status Indicator Raps
Launch Version
116-343 Main PWB IC RAP
An error is detected in the IC in the ESS PWB.
Initial Actions
Power Off/On
Procedure
Check the connection of each ESS PWB connector. The connectors are securely connected.
YN
Connect the connectors.
Switch on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the ESS PWB (PL 9.2).
116-346 Formatter RAP
Errors are detected by the Formatter.
Initial Actions
Power Off/On
Procedure
Pull out and insert or replace the DIMM (PL 9.2).
If the problem persists, replace the ESS PWB (PL 9.2).
To Next Page
