February, 2008
2-355
WorkCentre 5225, 5230
024-955, 024-958
Status Indicator Raps
Launch Version
024-955 Tray 6 Empty
Tray 6 is empty when attempting to feed from Tray 6.
Initial Actions
Load paper
Procedure
If failure continues, check for proper operation of the Tray 6 No Paper Sensor. (BSD 7.14)
024-958 MPT Size Failure RAP
The MPT is unable to detect the paper size.
Initial Actions
• Refer to BSD 7.13.
• Check the operation of the MPT Guide.
Procedure
Check the installation and operation of the MPT Guide. The MPT Guide is installed correctly
and the actuator works.
YN
Reinstall the MPT Guide.
Measure the voltage between the MCU PWB P411-3 (+) and GND (-) (BSD 7.13 Flag 1).
Manually operate the MPT Guide. As the MPT Guide moves, the voltage changes accord-
ingly.
YN
Check the connections of P/J107, P/J609, P/J605 and P/J411. P/J107, P/J609, P/
J605 and P/J411 are connected correctly.
YN
Connect P/J107, P/J609, P/J605 and P/J411.
Check the wire between J107 and J411 for an open circuit or a short circuit (BSD 7.13
Flag 1/Flag 2).
The wire between J107 and J411 is conducting without an open cir-
cuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P411-1 (+) and GND (-) (BSD 7.13 Flag 2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Replace the MPT Paper Size Sensor (PL 7.3).
Replace the MCU PWB (PL 9.1).
To Next Page
