Xerox WorkCentre 5225 Service Manual

February, 2008
6-61
WorkCentre 5225, 5230
General Procedures
Launch Version
Chain 770-xxx I/O Port Protocol
732-
001~999
Speed Dial setting for Super G3 (Link 1-
500=Dial
0: Do not prohibit 0~1 [0: Do not prohibit, 1: Prohibit]
733-
001~999
Speed Dial setting for ECM (Link 1-
500=Dial)
0: Do not prohibit 0~1 [0: Do not prohibit, 1: Prohibit]
734-
001~999
Speed Dial setting for JBIG (Link 1-
500=Dial)
0: Do not prohibit 0~1 [0: Do not prohibit, 1: Prohibit]
Table 4 Stored Data
Chain-
Link Content Default Range Meaning
Table 5 I/O Port Protocol
Chain-
Link
Content Default Range Meaning
770-001 Parallel Port Enable 1: Enable 0~1 0: Disable, 1: Enable
770-002 Parallel Print ModeType 1: Auto 1~29 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 9: 201H, 5: PostScript, 10: TIFF
2: PCL, 17: KS5843, 18: KSSM, 29: KS5895
770-003 Parallel JCL(FX)/PJL(AP) Switch On 0~1 0: Off, 1: On
770-004 Parallel Adobe Protocol 0: Standard 0~2 0: Standard, 1: Binary, 2: TBCP
770-005 Parallel Auto Feed Time 6 (30sec) 1~255 1~255 (5~1275 sec.) (unit: 5 sec.)
770-006 Parallel Input Prime 1 0~1 0: Off, 1: On
770-007 Parallel COMM Mode 0 0~1 0: On, 1: Off
770-009 Parallel Corresponding Standard 0: IEEE P1284 0~1 0: IEEE P1284, 1: Centronics
770-010 Ethernet Transfer Rate 127: Auto 1~127 127: Auto, 17: 10BASE-T (Half-Duplex), 18: 100BASE-TX (Half-Duplex), 33: 10BASE-T
(Full Duplex), 34: 100BASE-TX (Full Duplex)
770-011 JBA 2004 Extensions 0 0~1 0: Not supported, 1: Operates by expansion mode
770-012 Bonjour Port Enable 1 0~1 0: Disable, 1: Enable
770-020 TokenRing Transfer Rate 4 1~4 Auto: 4, 4MB/s: 1, 16MB/s: 2, 100MB/s: 3
770-021 TokenRing Packet Length 1500 1500, 2088, 4472, 8232
770-030 NetWare Frame Type 255: Auto 0~255 255: Auto 2: Ethernet II 4: Ethernet SNAP 3: Ethernet 802.2 1: Ethernet 802.3 6: Token
SNAP 5: Token 802.5
770-039 LPD Max Session 5 1~10 1 to 10
770-040 EtherTalk Port Enable 0: Disable 0~1 0: Disable, 1: Enable
770-041 EtherTalk Print Type 5: PostScript 5: PostScript
770-042 EtherTalk JCL(FX)/PJL(AP) Enable 1 0~1 0: Off, 1: On
770-050 Netware Port Enable 0: Disable 0~1 0: Disable, 1: Enable
770-051 Netware Print Mode Type 1: Auto 1~29 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10: TIFF, 2: PCL,
17: KS5843, 18: KSSM, 29: KS5895
770-052 Netware JCL(FX)/PJL(AP) Enable 1 0~1 0: Off, 1: On
770-053 NetWare TBCP Valid 0: None 0~1 0: None, 1: TBCP
770-054 NetWare Trans. Protocol 1: IPX/SPX 1~3 1: IPX/SPX, 2: TCP/IP, 3: Both
770-055 Burst transfer 1 0~1 0: Not used, 1: Used
770-060 Lpd Port Enable 1: Start 0~1 0: Stop, 1: Start
