Xerox WorkCentre 5225 Service Manual

February, 2008
2-363
WorkCentre 5225, 5230
024-977, 024-978
Status Indicator Raps
Launch Version
024-977 Stapler Feed Ready Failure RAP
When starting Staple, Staple Ready Sensor Off was detected.
Empty stapling was within 13 times.
Initial Actions
Refer to BSD 12.6.
Reload the Staple Cartridge.
Procedure
Execute Component Control[012-243]. Install and remove the Staple Cartridge. The display
changes.
YN
Check the Staple Cartridge for failure or foreign substances. There are no foreign sub-
stances and nothing has failed.
YN
Repair the failure and remove the foreign substances.
Check the connections of P/J8818 and P/J8852. P/J8818 and P/J8852 are connected
correctly.
YN
Connect P/J8818 and P/J8852.
Check the wire between J8818 and J8852 for an open circuit or a short circuit (BSD
12.6).
The wire between J8818 and J8852 is conducting without an open circuit or a
short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8852-1 (+) and GND (-) (BSD 12.6).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 22.7).
Measure the voltage between the Finisher PWB P8852-3 (+) and GND (-) (BSD 12.6).
Install and remove the Staple Cartridge.
The voltage changes.
YN
Replace the Finisher PWB (PL 22.7).
Replace the Staple Assembly (PL 22.4). If the problem persists, replace the Finisher PWB
(PL 22.7).
Replace the Finisher PWB (PL 22.7). If the problem persists, replace the MCU PWB (PL 9.1).
024-978 Booklet Stapler Fault
Booklet Maker Stapler not ready.
Initial Actions
Check staples, reset the stapler cartridge.
Procedure
Check for proper operation of the Booklet Stapler Cover Switch, and the Stapler Front Safety
Switches. (BSD 12.13)
