February, 2008
2-69
WorkCentre 5225, 5230
005-196
Status Indicator Raps
Launch Version
005-196 CVT Size Mismatch JAM (No Mix) RAP
The second and subsequent documents are different size to the first document.
Initial Actions
• Refer to BSD 5.1.
Procedure
Execute Component Control[005-221]. Actuate the DADF Tray Size 1 Sensor with paper. The
display changes.
YN
Check the connections of P/J771 and P/J759. P/J771 and P/J759 are connected cor-
rectly.
YN
Connect P/J771 and P/J759.
Check the wire between J771 and J759 for an open circuit or a short circuit (BSD 5.1 Flag
1/Flag 2).
The wire between J771 and J759 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P759-3 (+) and GND (-) (BSD 5.1 Flag 2).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P759-2 (+) and GND (-) (BSD 5.1 Flag 1).
Actuate the DADF Tray Size 1 Sensor with paper. The voltage changes.
YN
Replace the DADF Tray Size 1 Sensor (PL 15.10).
Replace the DADF PWB (PL 15.3).
Execute Component Control[005-222]. Actuate the DADF Tray Size 2 Sensor with paper. The
display changes.
YN
Check the connections of P/J772 and P/J759. P/J772 and P/J759 are connected cor-
rectly.
YN
Connect P/J772 and P/J759.
Check the wire between J772 and J759 for an open circuit or a short circuit (BSD 5.1 Flag
3/Flag 4).
The wire between J772 and J759 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P759-6 (+) and GND (-) (BSD 5.1 Flag 4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P759-5 (+) and GND (-) (BSD 5.1 Flag 3).
Actuate the DADF Tray Size 2 Sensor with paper. The voltage changes.
YN
Replace the DADF Tray Size 2 Sensor (PL 15.10).
Replace the DADF PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
A
A
B
B
To Next Page
