February, 2008
2-506
WorkCentre 5225, 5230
047-215, 047-216
Launch Version
Status Indicator Raps
047-215 MCU Exit Communication Error RAP
BSD-ON:1.2/3.2
Communication error occurred between the MCU PWB and the Exit Module.
Initial Actions
Check the Exit Module harness connections to the IOT.
Procedure
Check the connection of each MCU PWB connector. The connectors a re securely connected.
YN
Connect the connectors.
Check the connection of each Exit PWB connector. The connectors are securely connected.
YN
Connect the connectors.
Check the wire between P/J421 and P/J431 for an open circuit or a short circuit (BSD 3.2 Flag
2).
The wire between P/J421 and P/J431 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Replace the Exit PWB (PL 9.1) If the problem persists, replace the MCU PWB (PL 9.1).
047-216 MCU Finisher Communication RAP
BSD-ON:3.4
A communication error occurred between the MCU PWB and the Finisher Module.
Initial Actions
Check the Finisher harness connections to the IOT.
Procedure
Check the connection of each MCU PWB connector. The connectors are secu rely connected.
YN
Connect the connectors.
Check the connection of each Finisher PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Check the wire between P/J416 and J8989 for an open circuit or a short circuit (BSD 3.4).
The wire between P/J416 and J8989 is conducting without an open circuit or a short cir-
cuit.
YN
Repair the open circuit or short circuit.
Replace the Finisher PWB (PL 23.16) If the problem persists, replace the MCU PWB (PL 9.1).
