Xerox WorkCentre 5225 Service Manual

February, 2008
2-551
WorkCentre 5225, 5230
077-131
Status Indicator Raps
Launch Version
077-131 Duplex Wait Sensor On JAM RAP
BSD-ON:10.4/10.5
After the Exit 2 Motor turned On, the Duplex Sensor does not turn On within the specified time.
Initial Actions
• Power OFF/ON
Procedure
Check the installation of the DUP Module. The DUP Module is installed correctly.
YN
Install the DUP Module correctly.
Check the Transport Roll for wear and paper powder. The Transport Roll is ok.
YN
Replace the Transport Roll.
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Execute Component Control [071-105 Duplex Sensor]. Actuate the Duplex Sensor (PL 8.1)
with paper.
The display changes to L.
YN
Check the wire between P/J123 and P/J541 for an open circuit or a short circuit (BSD
10.5 Flag 1/Flag 2).
The wire between J123 and J541 is conducting without an open
circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Duplex Sensor (PL 8.1). If the problem persists, replace the Duplex PWB (PL
8.1).
Execute Component Control [073-016 Duplex Motor ON]. The Duplex Motor (PL 8.1) can be
heard.
YN
Check the wire between P/J212 and P/J542 for an open circuit or a short circuit (BSD
10.5 Flag 3).
The wire between J212 and J542 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Duplex Motor (PL 8.1). If the problem persists, replace the Duplex PWB (PL
8.1).
Execute Component Control [047-023 Exit 2 Motor ON]. The Exit 2 Motor (PL 6.4) can be
heard.
YN
Check the wire between P/J208 and P/J433 for an open circuit or a short circuit (BSD
10.4 Flag 1).
The wire between J208 and J433 is conducting without an open circuit
or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Exit 2 Motor (PL 6.4) between J208-1 (COM) and each
point of J208-2/3/4/5 (BSD 10.4 Flag 2).
The resistance is approx. 10Ohm.
YN
Replace the Exit 2 Motor (PL 6.4).
Replace the Exit 2 Motor (PL 6.4). If the problem persists, replace the Exit PWB (PL 9.1).
Replace the Duplex PWB (PL 8.1).
