Xerox WorkCentre 5225 Service Manual

February, 2008
2-684
WorkCentre 5225, 5230
124-362, 124-363
Launch Version
Status Indicator Raps
124-362 CRUM Validation System 1 RAP
CRUM control failed in system 1.
Initial Actions
Power Off/On
Procedure
Check the electrical connections on the ESS PWB and MCU PWB. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Perform GP 4, repair the problem by master MCU.
If the problem persists. replace the ESS PWB (PL 9.2).
124-363 CRUM validation System 2 RAP
CRUM control failed in system 2.
Procedure
Check the electrical connections on the ESS PWB and MCU PWB. The connectors are securely
connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Perform GP 4, repair the problem by master SYS2.
If the problem persists, replace the ESS PWB (PL 9.2).
