February, 2008
2-370
WorkCentre 5225, 5230
024-917, 024-928
Launch Version
Status Indicator Raps
024-917 Stacker Tray Staple Set Over Count RAP
The number of stapled copies exceeded the capacity of the Stacker Tray.
Procedure
Check the connection of each Finisher PWB connector. The connectors are connected cor-
rectly.
YN
Connect the connectors.
Turn on the power again. [024-917] reoccurs.
YN
End
Replace the Finisher PWB (PL 23.16). If the problem persists, replace the MCU PWB (PL 9.1).
024-928 Scratch Sheet Compile RAP
- When the eject cover is opened or closed, Compiler Tray No Paper Sensor has No Paper.
- A set of sheets including scratch sheet is output from compiler tray. (e.g. when job is can-
celled)
Initial Actions
Ensure that the Eject cover is closed
Procedure
Check the connection J8984 and P/J8988 on the Finisher PWB. The connectors are con-
nected correctly.
YN
Connect the connectors.
Turn on the power again. [024-928] reoccurs.
YN
End
Replace the Finisher PWB (PL 23.16).
To Next Page
