Xerox WorkCentre 5225 Service Manual

February, 2008
2-149
WorkCentre 5225, 5230
012-903
Status Indicator Raps
Launch Version
012-903 Paper Remains at Compiler Exit Sensor RAP
BSD-ON:12.16
Paper remains on the Compiler Exit Sensor.
Initial Actions
Remove foreign substances on the sensor.
Power OFF/ON
Procedure
Execute Component Control[012-150 Compile Exit Sensor]. Actuate the Compiler Exit Sensor
with paper.
The display changes.
YN
Check the connections of J8868 and P/J8988. J8868 and P/J8988 are connected
correctly.
YN
Connect J8868 and P/J8988.
Check the wire between J8868 and J8988 for an open circuit or a short circuit (BSD
12.16).
The wire between J8868 and J8888 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8988-3 (+) and GND (-) (BSD 12.16).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8988-2 (+) and GND (-) (BSD 12.16).
Actuate the Compiler Exit Sensor with paper. The voltage changes.
YN
Replace the Compiler Exit Sensor (PL 23.14).
Replace the Finisher PWB (PL 23.16).
Replace the Finisher PWB (PL 23.16).
