Xerox WorkCentre 5225 Service Manual

February, 2008
2-124
WorkCentre 5225, 5230
012-161
Launch Version
Status Indicator Raps
012-161 Finisher Set Eject JAM RAP
BSD-ON:12.19/12.22
After the Eject Motor turned On, the Compile No Paper Sensor did not turn Off within the spec-
ified time.
Initial Actions
• Power OFF/ON
Procedure
Execute Component Control[012-151 Compile No Paper Sensor]. Actuate the Compile No
Paper Sensor with paper.
The display changes.
YN
Check the connections of J8880 and J8984. J8880 and J8984 are connected cor-
rectly.
YN
Connect J8880 and J8984.
Check the wire between J8880 and J8984 for an open circuit or a short circuit (BSD
12.19).
The wire between J8880 and J8984 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8984-3 (+) and GND (-) (BSD 12.19).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8984-2 (+) and GND (-) (BSD 12.19).
Actuate the Compile Paper Sensor with paper. The voltage changes.
YN
Replace the Compile Paper Sensor (PL 23.12).
Replace the Finisher PWB (PL 23.16).
Alternately execute Component Control[012-054 Eject Motor FORWARD LO] and Component
Control[012-055 Eject Motor FORWARD HI].
The Eject Motor starts up.
YN
Check the connections of P/J8878 and P/J8983. P/J8878 and P/J8983 are con-
nected correctly.
YN
Connect P/J8878 and P/J8983.
Check the wire between J8878 and J8983 for an open circuit or a short circuit (BSD
12.22).
The wire between J8878 and J8983 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the resistance of the Eject Motor between each point of J8878-1/3/4/6 (BSD
12.22).
The resistance is approx. 2Ohm.
YN
Replace the Eject Motor (PL 23.11).
Measure the voltage between the Finisher PWB (PL 23.16) J8983-5/6/7/8 (+) and GND (-
), and between P8846-12 (+) and GND (-) (BSD 12.22).
The voltage is approx.
+24VDC.
YN
Replace the Finisher PWB (PL 23.16).
Replace the Eject Motor (PL 23.11). If the problem persists, replace the Finisher PWB (PL
23.16).
Replace the Finisher PWB (PL 23.16).
A
A
B
B
