Xerox WorkCentre 5225 Service Manual

February, 2008
2-567
WorkCentre 5225, 5230
091-402, 091-441
Status Indicator Raps
Launch Version
091-402 Drum Life Over RAP
The Drum Cartridge must be replaced.
Procedure
Check the HSFI counter. The usage is correct for the life expectancy of the drum.
YN
There is no need for service at this time. Return to Service Call Procedures.
Replace the Drum Cartridge (PL 4.1).
091-441 Drum Life Near End of Life RAP
The Drum Cartridge must be replaced soon.
Procedure
Check the HSFI counter. The usage is correct for the life expectancy of the drum.
YN
There is no need for service at this time. Return to Service Call Procedures.
Replace the Drum Cartridge (PL 4.1).
