Xerox WorkCentre 5225 Service Manual

February, 2008
2-58
WorkCentre 5225, 5230
005-125
Launch Version
Status Indicator Raps
005-125 CVT Registration Sensor Off JAM RAP
After the Pre Registration Sensor turned Off during the Read operation, the DADF Registration
Sensor did not turn Off within the specified time.
Initial Actions
• Refer to BSD 5.4/5.5.
Procedure
Execute Component Control[005-110]. Actuate the DADF Registration Sensor (PL 15.7) with
paper.
The display changes.
YN
Check the connections of P/J782 and P/J761. P/J782 and P/J761 are connected cor-
rectly.
YN
Connect P/J782 and P/J761.
Check the wire between J782 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
1/Flag 2).
The wire between J782 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-15 (+) and GND (-) (BSD 5.4 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P761-14 (+) and GND (-) (BSD 5.4 Flag 1).
Actuate the DADF Registration Sensor with paper. The voltage changes.
YN
Replace the DADF Registration Sensor (PL 15.7).
Replace the DADF PWB (PL 15.3).
Execute Component Control[005-001]. The DADF Feed Motor (PL 15.9) starts up.
YN
Check the connections of P/J764 and P/J754. P/J764 and P/J754 are connected cor-
rectly.
YN
Connect P/J764 and P/J754.
Check the wire between J764 and J754 for an open circuit or a short circuit (BSD 5.5 Flag
1).
The wire between J764 and J754 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB (PL 15.3) P754-1 (+) and GND (-), and
between P754-7 (+) and GND (-) (BSD 5.5 Flag 1).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 15.3).
Replace the DADF Feed Motor (PL 15.9). If the problem persists, replace the DADF PWB
(PL 15.3).
Execute Component Control[005-026]. The DADF Registration Motor (PL 15.9) starts up.
YN
Check the connections of P/J765 and P/J755. P/J765 and P/J755 are connected cor-
rectly.
YN
Connect P/J765 and P/J755.
Check the wire between J765 and J755 for an open circuit or a short circuit (BSD 5.5 Flag
2).
The wire between J765 and J755 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB (PL 15.3) P755-1 (+) and GND (-), and
between P755-6 (+) and GND (-) (BSD 5.5 Flag 2).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 15.3).
Replace the DADF Registration Motor (PL 15.9). If the problem persists, replace the
DADF PWB (PL 15.3).
Replace the DADF PWB (PL 15.3).
A
A
B
B
