Xerox WorkCentre 5225 Service Manual

February, 2008
2-543
WorkCentre 5225, 5230
077-101
Status Indicator Raps
Launch Version
077-101 Registration Sensor Off JAM RAP
BSD-ON:8.7
After the Registration Clutch turned On, the Registration Sensor did not turn Off within the
specified time.
Initial Actions
• Power OFF/ON
Procedure
Check the Transport Roll for wear and paper powder. The Transport Roll is ok.
YN
Replace the Transport Roll.
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Execute Component Control [089-100 Registration Sensor]. Manually activate the actuator of
the Registration Sensor (PL 2.4).
The display changes.
YN
Check the connection of P/J104 and P/J403. P/J104 and P/J403 are connected cor-
rectly.
YN
Connect P/J104 and P/J403.
Check the wire between J104 and J403 for an open circuit or a short circuit (BSD 8.7 Flag
1/Flag 2).
The wire between J104 and J403 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P403B-13 (+) and GND (-) (BSD 8.7 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P403B-8 (+) and GND (-) (BSD 8.7 Flag 1).
Actuate the Registration Sensor with paper. The voltage changes.
YN
Replace the Registration Sensor (PL 2.4).
Replace the MCU PWB (PL 9.1).
Execute Component Control [089-002 Registration Clutch ON]. The Registration Clutch (PL
2.4) can be heard.
YN
Check the connection of P/J215 and P/J403. P/J215 and P/J403 are connected cor-
rectly.
YN
Connect P/J215 and P/J403.
Measure the resistance of the Registration Clutch (PL 2.4) between P215-1 and P215-2
(BSD 8.7 Flag 3).
The resistance is approx. 240Ohm.
YN
Replace the Registration Clutch (PL 2.4).
Check the wire between J215 and J403 for an open circuit or a short circuit (BSD 8.7 Flag
3).
The wire between J215 and J403 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
A
A
