Xerox WorkCentre 5225 Service Manual

February, 2008
6-124
WorkCentre 5225, 5230
Component Control
Launch Version
General Procedures
Stacking Component Codes
NOTE: Some components cannot be energized at the same time as another component. If you
activate such a combination of components, the first component switched on will be automati
-
cally switched off.
1. When perform multiple component checking. input new Chain-Link number after one (or
several) component(s) is (are) in operating.
NOTE: Only latest Chain-Link number indicates.
2. When confirm the status of another component still in progress, select Enter Number then
input Chain-Link number of applicable component.
3. Select Stop key after confirming.
Stop operation of component indicated on screen.
NOTE: There are no Cyclic Component in below category:
• IIT Input Component.
• IIT Output Component.
• IOT Input Component.
Table 1 Input Component Control Codes IOT
Chain-Link Name
Connector
Level
Meaning Remarks
010-100 EXIT SENSOR L with paper Not Available
010-101 EXIT SENSOR1(EXIT) H with paper Sensor level detected by EXIT MODULE EXIT
010-200 Fuser Control Sensor FS1 Analog Min 0, Max 1023 Standby temperature monitor
010-201 Fuser Control Sensor FS2 Analog Min 0, Max 1023 Standby temperature monitor
012-100 Transport Entrance Sensor H with paper (M1-1); without paper (M1-1.5)
012-110 Registration Clutch ON H IOT Regi Clutch OFF (A-Finisher, B/C-Finisher); IOT Regi Clutch ON (SB-
Finisher)
Not Available
012-111 IOT Exit Sensor H with paper (A-Finisher, B/C-Finisher); without paper (SB-Finisher) Not Available
012-140 Entrance Sensor H with paper Not available
012-150 Compile Exit Sensor H with paper (A-Finisher, B/C-Finisher, SB-Finisher M1-1) Not Available
012-151 Compile Tray No Paper Sensor H with paper (B/C-Finisher) SB-Finisher:
Before Sensor change: H with paper
After Sensor change: H without paper
012-190 H-Transport Ent. Sensor H with paper Not Available
012-191 H-Transport Exit Sensor H with paper Not Available
012-220 Front Tamper Home Sensor H home position (B/C, SB-Finishers); other than home position (A-Finisher) Not Available
012-221 Rear Tamper Home Sensor H home position (B/C, SB-Finishers); other than home position (A-Finisher) Not Available
012-240 Stapler Move Home Sensor H other than home position Not Available
012-241 Stapler Move Position Sensor H other than home position (B/C-Finisher); Stapler Unit position detection (SB-
Finisher)
Not Available
012-242 Low Staple Sensor H without staples (A, B/C-Finishers); without/low staples (SB-Finisher) Not Available
012-243 Self Priming Sensor H staple not ready (A, B/C-Finishers); staple ready (SB-Finisher) Not Available
012-244 Staple Home Sensor H other than home position Not Available
012-250 Eject Clamp Home Sensor H other than home position Not Available
012-251 Set Clamp Home Sensor H other than home position Not Available
012-252 Eject Home Sensor H other than home position Not Available
012-260 Upper Limit Sensor H upper limit position Not Available
012-262 Stacker No Paper Sensor H without paper (B/C-Finisher) uppermost position of Stacker Tray
detected (no paper) (SB-Finisher)
012-263 Stack Encoder Sensor H Encoder pulse detected
012-264 Stack Height Sensor 1 H paper detected (C-Finisher) Stacker Tray position detected (SB-Fin-
isher)
