Xerox WorkCentre 5225 Service Manual

February, 2008
2-522
WorkCentre 5225, 5230
071-210
Launch Version
Status Indicator Raps
071-210 Tray 1 Lift Up Failure RAP
BSD-ON:7.7
After the Tray 1 Feed/Lift Motor turned On, the Tray 1 Level Sensor did not turn On within the
specified time.
• Initial Actions
Procedure
Remove the tray and reinstall. The Tray 1 Feed/Lift Motor can be heard.
YN
Execute Component Control[071-007 Tray 1 Feed/Lift Motor ON]. The Tray 1 Feed/Lift
Motor (PL 2.3) can be heard.
YN
Check the connections of P/J201, P/J601 and P/J409. P/J201, P/J601 and P/
J409 are connected correctly.
YN
Connect P/J201, P/J601 and P/J409.
Remove the Tray 1 Feed/Lift Motor (PL 2.3) and the Tray 2 Feed/Lift Motor (PL 2.3).
Replace the Tray 1 Feed/Lift Motor with the Tray 2 Feed/Lift Motor.
Execute Component Control[071-007 Tray 1 Feed/Lift Motor ON]. The Tray 2 Feed/
Lift Motor (PL 2.3) can be heard.
YN
Return the Tray 2 Feed/Lift Motor to its original position.
Check the wire between J201 and J409 for an open circuit or a short circuit
(BSD 7.7 Flag 1).
The wire between J201 and J409 is conducting without
an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the MCU PWB (PL 9.1).
Return the Tray 2 Feed/Lift Motor to its original position.
Replace the Tray 1 Feed/Lift Motor (PL 2.3).
Go to the OF 2 (SIZE SWITCH ASSY RAP).
Check the installation of the Tray 1 Level Sensor (PL 2.3) and the operation of the actuator.
The Tray 4 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 4 Level Sensor.
Execute Component Control[071-206 Tray 1 Level Sensor]. Manually activate the Tray 1 Level
Sensor (PL 2.3).
The display changes.
YN
Check the connections of P/J100, P/J601 and P/J409. P/J100, P/J601 and P/J409
are connected correctly.
YN
Connect P/J100, P/J601 and P/J409.
Check the wire between J100 and J409 for an open circuit or a short circuit (BSD 7.7 Flag
2/Flag 3).
The wire between J100 and J409 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P409A-7 (+) and GND (-) (BSD 7.7 Flag 3).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P409A-9 (+) and GND (-) (BSD 7.7 Flag 2).
Activate the actuator of the Tray 1 Level Sensor (PL 2.3). The voltage changes.
YN
Replace the Tray 1 Level Sensor (PL 2.3).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
A
A
