Xerox WorkCentre 5225 Service Manual

February, 2008
6-9
WorkCentre 5225, 5230
IOT NVM List
General Procedures
Launch Version
Chain 741-xxx Drive
Chain 741-xxx NOHAD
Chain 740-xxx Chain 742-xxx Chain 760-xxx PH
Table 3 Drive
Chain-
Link
Name Default Range 1 Count Remarks
741-001 Fine-Tuning of Main and Drum Motor Speed 24 0~53 0.1% Diag50-28 Adjust Main and Drum Motor Speed at the same time so that they rotate at the
same speed. Min(0)=-2.7%, Max(53)=2.6%, Initial(27)=0%
Table 4 NOHAD
Chain-
Link
Name Default Range 1 Count Remarks
741-509 Non-condensation mode - 0~1 1 0: Normal mode 1: Condensation mode
741-510 Condensation Time 0 0~120 1 minute
741-519 ROS Fan Control Temp 24 15~30 1 deg.C Threshold temperature for operating ROS Fan during print
741-520 ROS Fan Off Delay Time 10 6~14 1 sec. Time period during which ROS Fan stops (ROS Motor is off) after print ends
Table 5 PH
Chain-
Link
Name Default Range 1 Count Remarks
740-090 Output Tray 0 0~4 - 0: FACE DOWN TRAY#1, 1: FACE DOWN TRAY#2, 2: FACE UP TRAY, 3: FINISHER
Bin1, 4: FINISHER Top Tray
742-003 Exit SNR1 Short Off Check 0 0~1 - 0: Enable 1: Disable
742-006 TRAY2 for Heavyweight2 Paper - LEAD REGI
ADJUSTMENT
33 0~66 0.363mm Image input is delayed when Set Value is increased.
742-012 TRAY2 for Heavyweight2 Paper - REGI LOOP
TIMER
24 0~66 0.435mm Loop increases when Set Value is increased.
742-015 The Timer which turns OFF TACL 87 37~137 3.0ms Not available
742-018 The Timer which turns ON TACL 11 0~41 3.0ms Not available
742-027 LEAD REGI ADJUSTMENT - ALL TRAY 26 0~66 0.2175mm Image input is delayed when Set Value is increased. Min(0)=-7.18mm, Max(66)=7.18mm,
Initial(26)=-1.5225mm
742-030 INVERT TIMING - ALL TRAY 33 0~66 0.435mm Invert timing is delayed when Set Value is increased. Min(0)=-14.96mm,
Max(66)=14.96mm, Initial(33)=0mm
742-031 Exit Gate Solenoid On Time 50 47~53 10 ms
742-032 Exit Gate Solenoid Off Time 0 0~99 10 ms
742-090 Paper Path Sensor (Tray Module) - 0~127 - Bit0: Not available Bit1: Not available Bit2: PREFEED #2 SENSOR Bit3: PREFEED #1
SENSOR Bit4: FEED OUT#4 SENSOR Bit5: FEED OUT#3 SENSOR Bit6: FEED OUT#2
SENSOR Bit7: * The meaning of the bit, 0: Out of paper, 1: Paper detected. The renewal
precision is 10 ms.
742-091 Paper Path Sensor (HCF / DM / EXIT/ IOT) - 0~127 - Bit0: HCF PREFEED SENSOR Bit1: HCF FEED OUT SENSOR Bit2: DM WAIT SEN-
SOR Bit3: EXIT#2 SENSOR Bit7: EXIT#1 SENSOR Bit6: REGI SENSOR * The meaning
of the bit, 0: Out of paper, 1: Paper detected. The renewal precision is 10 ms.
