February, 2008
2-555
WorkCentre 5225, 5230
077-308, 077-309
Status Indicator Raps
Launch Version
077-308 Left Hand HIGH Interlock Open RAP
BSD-ON:1.4
The L/H-H Cover is open.
Initial Actions
Power OFF/ON
Opening/closing of the IOT L/H-H Cover.
Procedure
Check opening/closing of the IOT L/H-H Cover. The IOT L/H-H Cover can be opened/
closed.
YN
Reinstall the IOT L/H-H Cover.
Check the installation of the Exit 2 Interlock Switch. The Exit 2 Interlock Switch is installed
correctly.
YN
Install the Exit 2 Interlock Switch correctly.
Execute Component Control [071-304 Exit 2 Interlock Switch]. Open/close the IOT L/H-H
Cover.
The display changes.
YN
Check the connections of P/J434, P/J116, P606, J606 and SJ1. The P/J434, P/J116,
P606, J606 and SJ1 are connected correctly.
YN
Connect P/J434, P/J116, P606, J606 and SJ1.
Check the wire between J434 and J116 for an open circuit or a short circuit (BSD 1.4 Flag
7/Flag 8).
The wire between J434 and J116 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Exit 2 Interlock Switch (PL 6.4) between J434-12 and J434-
13 (BSD 1.4 Flag 7/Flag 8).
The wire between J434-12 and J434-13 is connecting
successfully when the IOT L/H-H Cover is closed, and is insulated when the cover
is open.
YN
Replace the Exit 2 Interlock Switch (PL 6.4).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
077-309 Left Hand Low Interlock Open RAP
BSD-ON:1.4
The L/H Lower Cover is open.
Initial Actions
Power OFF/ON
Opening/closing the L/H Lower Cover.
Procedure
Check opening/closing of the L/H Lower Cover. The L/H Lower Cover can be opened/
closed.
YN
Reinstall the L/H Lower Cover (PL 2.5).
Check the installation of the L/H Lower Cover Interlock Switch. The L/H Lower Cover Inter-
lock Switch is installed correctly.
YN
Install the L/H Lower Cover Interlock Switch (PL 2.5) correctly.
Execute Component Control [071-302 L/H Lower Cover Interlock Switch]. Open/close the L/H
Lower Cover.
The display changes.
YN
Check the connections of P/J106 and P/J410. P/J106 and P/J410 are connected cor-
rectly.
YN
Connect P/J106 and P/J410.
Check the wire between J106 and J410 for an open circuit or a short circuit (BSD 1.4 Flag
1/Flag 2).
The wire between J106 and J410 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the L/H Lower Cover Interlock Switch (PL 2.5) between J410-11
and J410-12 (BSD 1.4 Flag 1/Flag 2).
The wire between J410-11 and J410-12 is con-
necting successfully when the L/H Lower Cover is closed, and is insulated when
the cover is open.
YN
Replace the L/H Lower Cover Interlock Switch (PL 2.5).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
