February, 2008
2-358
WorkCentre 5225, 5230
024-965
Launch Version
Status Indicator Raps
024-965 ATS/APS No Paper (IOT detect) RAP
No paper is loaded in the tray.
Initial Actions
Refer to BSD 7.7/7.8/7.9/7.10/7.11/7.12.
Reload the relevant tray.
Procedure
Check the actuator of the relevant No Paper Sensor (PL 2.3/PL 12.3/PL 13.6). The actuator
is not distorted or damaged.
YN
Replace the actuator.
Actuate the actuator of the relevant No Paper Sensor (PL 2.3/PL 12.3/PL 13.6).
Tray 1: Component Control[071-201 Tray 1 No Paper Sensor]
Tray 2: Component Control[071-202 Tray 2 No Paper Sensor]
Tray 3: Component Control[071-203 Tray 3 No Paper Sensor]
Tray 4: Component Control[071-204 Tray 4 No Paper Sensor]
The display changes.
YN
Check the connections of the following connectors:
Tray 1: P/J101, P/J601, P/J409
Tray 2: P/J103, P/J602, P/J409
Tray 3: P/J102B, P/J661B, P/J549
Tray 4: P/J102A, P/J661A, P/J549
The connectors are connected correctly.
YN
Connect the connectors.
Check the following harnesses for an open circuit or a short circuit.
Tray 1: Between J101 and J409 (BSD 7.7 Flag 4/Flag 5)
Tray 2: Between J103 and J409 (BSD 7.8 Flag 4/Flag 5)
Tray 3: Between J102B and J549 (BSD 7.9 Flag 4/Flag 5/ BSD 7.10 Flag 4/Flag 5
Tray 4: Between J102A and J549 (BSD 7.11 Flag 4/Flag 5)/ BSD 7.12 Flag 4/Flag 5)
The relevant harnesses are conducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the following points (+) and GND (-).
Tray 1: MCU PWB P409A-10 (BSD 7.7 Flag 5)
Tray 2: MCU PWB P409B-10 (BSD 7.8 Flag 5)
Tray 3: TM PWB P549-B10 (BSD 7.9 Flag 5 / BSD 7.10 Flag 5)
Tray 4: TM PWB P549-A10 (BSD 7.11 Flag 5 / BSD 7.12 Flag 5)
The voltage is approx. +5VDC.
YN
Replace the relevant PWB (MCU PWB (PL 9.1) or the Tray Module PWB (PL 12.6/
PL 13.8).
Measure the voltage between the MCU PWB P409A-12 (+) and GND (-).
Tray 1: MCU PWB P409A-12 (BSD 7.7 Flag 4)
Tray 2: MCU PWB P409B-12 (BSD 7.8 Flag 4)
Tray 3: TM PWB P549-B12 (BSD 7.9 Flag 4 / BSD 7.10 Flag 4)
Tray 4: TM PWB P549-A12 (BSD 7.11 Flag 4 / BSD 7.12 Flag 4)
Activate the actuator of the relevant No Paper Sensor (PL 2.3/PL 12.3/PL 13.6). The
voltage changes.
YN
Replace the relevant No Paper Sensor (PL 2.3/PL 12.3/PL 13.6).
Replace the relevant PWB (MCU PWB (PL 9.1) or Tray Module PWB (PL 12.6/PL 13.8).
For Tray 1 or Tray 2, replace the MCU PWB (PL 9.1).
For Tray 3 or Tray 4, replace the Tray Module PWB (PL 12.6/PL 13.8).
