Xerox WorkCentre 5225 Service Manual

February, 2008
2-365
WorkCentre 5225, 5230
024-980, 024-981
Status Indicator Raps
Launch Version
YN
Repair the open circuit or short circuit.
Replace the Stacker Motor (PL 22.8). If the problem persists, replace the Finisher PWB
(PL 22.7).
Replace the Finisher PWB (PL 22.7). If the problem persists, replace the MCU PWB (PL 9.1).
024-981 Finisher Top Tray Full
Finisher top tray is full
Initial Actions
Remove paper from the Finisher Top Tray.
Procedure
If the failure continues, check for proper operation of the Stack Height Sensor. (BSD 12.8)
A
