Xerox WorkCentre 5225 Service Manual

February, 2008
2-353
WorkCentre 5225, 5230
024-951, 024-952
Status Indicator Raps
Launch Version
024-951 Tray 2 Empty RAP
Tray 2 has run out of paper.
Initial Actions
• Refer to BSD 7.8.
Procedure
Check the installation of the Tray 2 No Paper Sensor (PL 2.3) and the operation of the actua-
tor. The Tray 2 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 2 Level Sensor.
Execute Component Control [071-202 Tray 2 No Paper Sensor]. Manually activate the Tray 2
No Paper Sensor (PL 12.3).
The display changes.
YN
Check the connections of P/J103, P/J602 and P/J409. P/J103, P/J602 and P/J409
are connected correctly.
YN
Connect P/J103, P/J602 and P/J409.
Check the wire between J103 and J409 for an open circuit or a short circuit (BSD 7.8 Flag
4/Flag 5).
The wire between J103 and J409 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P409B-10 (+) and GND (-) (BSD 7.8 Flag
5).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P409B-12 (+) and GND (-) (BSD 7.8 Flag
4).
Activate the actuator of the Tray 2 No Paper Sensor (PL 2.3). The voltage changes.
YN
Replace the Tray 2 No Paper Sensor (PL 2.3).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
024-952 Tray 3 Empty RAP
Tray 3 has run out of paper.
Initial Actions
• Refer to BSD 7.9/7.11.
Procedure
Check the installation of the Tray 3 No Paper Sensor (PL 12.3/PL 13.6) and the operation of
the actuator.
The Tray 3 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 3 Level Sensor.
Execute Component Control[071-203 Tray 3 No Paper Sensor]. Manually activate the Tray 3
No Paper Sensor (PL 12.3/PL 13.6).
The display changes.
YN
Check the connections of P/J102B, P/J661B and P/J549. P/J102B, P/J661B and P/
J549 are connected correctly.
YN
Connect P/J102B, P/J661B and P/J549.
Check the wire between J102B and J549 for an open circuit or a short circuit (BSD 7.9
Flag 4/Flag 5 / BSD 7.11 Flag 4/Flag 5).
The wire between J102B and J549 is con-
ducting without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Tray Module PWB P549-B10 (+) and GND (-) (BSD 7.9
Flag 5 / BSD 7.11 Flag 5).
The voltage is approx. +5VDC.
YN
Replace the Tray Module PWB (PL 12.6/PL 13.8).
Measure the voltage between the Tray Module PWB P549-B12 (+) and GND (-) (BSD 7.9
Flag 4 / BSD 7.11 Flag 4).
Activate the actuator of the Tray 3 No Paper Sensor (PL 12.3/PL 13.6). The voltage
changes.
YN
Replace the Tray 3 No Paper Sensor (PL 12.3/PL 13.6).
Replace the Tray Module PWB (PL 12.6/PL 13.8).
Replace the Tray Module PWB (PL 12.6/PL 13.8).
