Close the current display and end the fun-
ction.
In addition, in vehicles with parking aids .
Red graphic segment: obstacle near. The
vehicle is in danger. Brake.
The auxiliary guidance lines in the area of this
chamber.
Automatic
brake
intervention
Yellow graphic segment: obstacle in the
path.
The vehicle is in danger. Turn the
vehicle around
.
White graphic segment: obstacle out of
the path of the vehicle.
The system has a fault in the scratched area
(depending on equipment). The colour may
vary.
Switching to the reversing assistant
→ p. 161.
Additionally for vehicles with
reversing
assistant
Red line: delimitation or safety distance.
Green side lines: extension of the vehicle.
Switch to parking assistance
→ p. 160.
Acoustic
signals
When the distance to the obstacle is sufficient, an
intermittent signal sounds. The shorter the
distance, the shorter the signal intervals become.
If the vehicle comes too close to the obstacle, a
continuous signal sounds. Do not continue
driving!
Only optical and acoustic warnings of obstacles in
the vehicle's path are given.
The system displays orientation lines in the
camera image independently of the vehicle's
surroundings. The cameras do not detect auto
The driver has to assess himself whether the vehicle
will fit in the parking space. The driver has to
assess himself whether the vehicle fits into the
parking space.
When a camera is mounted on the tailgate and
the tailgate is open, all the images are hidden.
When does an automatic
brake
intervention take
place
?
The following requirements must be met for
automatic brake intervention:
—
The vehicle does not exceed approx. 10 km/h (6
mph) when manoeuvring.
—
A parking system with automatic brake
intervention function is active.
—
The system detects an obstacle.
Automatic brake intervention does not occur when
the parking aid has been automatically engaged
during forward travel.
→ p. 160.
What happens in case of automatic
brake
intervention
?
—
The system brakes the vehicle to a standstill
and holds it for approx. 2 seconds.
Connect
—
Automatic brake intervention is activated as soon
as a parking system is activated.
—
Press the function button on the infotainment
system display to manually activate the
manoeuvring braking function.
Disconnect
—
The automatic freeze intervention function is
deactivated as soon as a parking system is
deactivated.
—
OR: press the function button on the
infotainment system panel to manually
deactivate the parking aid's manoeuvring
braking function.
The automatic brake intervention of a parking
system serves to reduce the danger of
collision when an obstacle is detected during
the parking operation.
