REAR LATCH STRIKER
REMOVAL
(1) Open door.
(2) Remove bolts and remove striker. (Fig. 14)
INSTALLATION
(1) Install striker and bolts.
(2) Tighten bolts to 25 N·m (18 ft. lbs.)
(3) Adjust striker if necessary. (Refer to 23 -
BODY/DOORS - SLIDING/SLIDING DOOR -
ADJUSTMENTS)
SLIDING DOOR
REMOVAL
(1) Disconnect and isolate battery negative cable.
(2) Remove the screws and remove the center
track end piece. (Fig. 15)
(3) Remove the screws and remove the stop
bumper.
(4) Remove the screws attaching the lower roller
arm to door.
(5) Support door with a suitable lifting device and
roll off the upper and center tracks towards the rear
of vehicle.
Fig. 14 LATCH STRIKER
1 - STRIKER
2 - BOLTS
Fig. 15 SLIDING DOOR
1 - STOP BUMPER
2 - SCREWS (2)
3 - SCREWS (2)
4 - LOWER ROLLER ARM
5 - END PIECE
6 - SCREWS (2)
VA DOORS - SLIDING 23 - 41
