MARKER LAMP NO. 2-LEFT FRONT

CAV CIRCUIT FUNCTION

1 16GY/BK LAMP DRIVER

2 16BR GROUND

MARKER LAMP NO. 2-RIGHT FRONT

CAV CIRCUIT FUNCTION

1 16GY/RD LAMP DRIVER

2 16BR GROUND

MARKER LAMP-LEFT CENTER

CAV CIRCUIT FUNCTION

1 16GY/BK LAMP DRIVER

2 16BR GROUND

MARKER LAMP-LEFT REAR

CAV CIRCUIT FUNCTION

1 16GY/BK LAMP DRIVER

2 16BR GROUND

MARKER LAMP-RIGHT CENTER

CAV CIRCUIT FUNCTION

1 16GY/RD LAMP DRIVER

2 16BR GROUND

VA 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 51
