TURN SIGNAL NO. 2-RIGHT FRONT
CAV CIRCUIT FUNCTION
1 16BK/DG RIGHT TURN SIGNAL
2 16BR GROUND
WARM AIR AUXILIARY HEATER ASSEMBLY C1
CAV CIRCUIT FUNCTION
1 16YL HEATER TIMER (CUT-IN SIGNAL)
2 14RD FUSED B(+)
3 20BK/YL PCI BUS
4 14BR GROUND
5 16BR/WT HEATER TIMER
6 16GY/RD HEATER TIMER
7 16WT/RD WARM AIR AUXILIARY HEATER CONTROL
WARM AIR AUXILIARY HEATER ASSEMBLY C2
CAV CIRCUIT FUNCTION
1 16DG/RD METERING PUMP DRIVER
2 16BR METERING PUMP GROUND
WASHER PUMP MOTOR-FRONT
CAV CIRCUIT FUNCTION
1 16BR GROUND
2 16BK/VT/RD WASHER ON/OFF SWITCH OUTPUT
WATER CYCLE VALVE
CAV CIRCUIT FUNCTION
1 18BR/VT WATER CYCLE VALVE CONTROL
2 18BR GROUND
8W - 80 - 64 8W-80 CONNECTOR PIN-OUTS VA
