HEATED SEAT MODULE-PASSENGER
CAV CIRCUIT FUNCTION
1 16VT/BR HEATED SEAT SWITCH-PASSENGER LOW OUTPUT
2 16VT/BK S363 COMMON CIRCUIT
3 16VT/BK S363 COMMON CIRCUIT
4 16VT/BR GROUND
HEATED SEAT SWITCH-DRIVER
CAV CIRCUIT FUNCTION
1 16GY/DG/RD PANEL LAMPS DRIVER
3 16VT/YL FUSED OPTIONAL EQUIPMENT RELAY OUTPUT
4 16VT/RD S366 COMMON CIRCUIT
5 16BR GROUND
7 16VT/DG HEATED SEAT SWITCH-DRIVER LOW OUTPUT
8 16VT/YL FUSED OPTIONAL EQUIPMENT RELAY OUTPUT
10 16BR GROUND
HEATED SEAT SWITCH-PASSENGER
CAV CIRCUIT FUNCTION
1 16DG/RD PANEL LAMPS DRIVER
3 16VT FUSED OPTIONAL EQUIPMENT RELAY OUTPUT
4 16VT/BK S363 COMMON CIRCUIT
5 16BR GROUND
7 16VT/BR HEATED SEAT SWITCH-PASSENGER LOW OUTPUT
8 16VT FUSED OPTIONAL EQUIPMENT RELAY OUTPUT
10 16BR GROUND
HEATER TIMER-AUXILIARY
CAV CIRCUIT FUNCTION
1 16GY/DG/RD LAMP DRIVER
2 16YL (EXCEPT PROGRAM TIMER) HEATER TIMER (CUT-IN SIGNAL)
2 16YL (PROGRAM TIMER) CABIN HEATER CONTROL
4 16BR GROUND
6 16GY/RD HEATER TIMER
9 16BR/WT HEATER TIMER
10 16BK/BL/DG S201 COMMON CIRCUIT
11 16RD FUSED B(+)
12 16BR GROUND
VA 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 41
