FUEL SHUTDOWN SOLENOID
CAV CIRCUIT FUNCTION
1 20BR/YL FUEL SHUTDOWN SOLENOID CONTROL
2 18RD/BK FUEL SHUTDOWN SOLENOID 12 VOLT SUPPLY
FUEL TEMPERATURE SENSOR
CAV CIRCUIT FUNCTION
1 18DG/BK SENSOR GROUND
2 18BL/GY FUEL TEMPERATURE SENSOR SIGNAL
FUSE BLOCK NO. 1 C1
CAV CIRCUIT FUNCTION
1 INTERNAL FOG LAMP SWITCH OUTPUT
3 INTERNAL HIGH BEAM SWITCH OUTPUT
4 16RD/BL FUSED RIGHT LAMP RELAY OUTPUT
5 INTERNAL HIGH BEAM SELECT
6 INTERNAL FUSED LEFT RELAY OUTPUT
8 INTERNAL LAMP DRIVER
9 INTERNAL FUSED IGNITION SWITCH OUTPUT (RUN-START)
10 INTERNAL FUSED B(+)
11 INTERNAL TURN SIGNAL RELAY OUTPUT
14 INERNAL GROUND
15 INTERNAL WIPER SWITCH OUTPUT
16 INTERNAL WIPER SWITCH OUTPUT
18 INTERNAL FUSED IGNITION SWITCH OUTPUT (RUN-START)
19 INTERNAL 12 VOLT SUPPLY
21 INTERNAL WIPER ON/OFF SWITCH OUTPUT
22 INTERNAL FUSED B(+)
FUSE BLOCK NO. 1 C2
CAV CIRCUIT FUNCTION
1 14BK/RD FUSED IGNITION SWITCH OUTPUT (RUN)
2 14BK/YL FUSED IGNITION SWITCH OUTPUT (START)
3 16GY/DG FUSED IGNITION SWITCH OUTPUT (ACC OFF)
4 14BK FUSED IGNITION SWITCH OUTPUT (RUN-START)
5 12BK/BL FUSED ENGINE CONTROL RELAY OUTPUT
VA 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 37
