FRAME

SPECIFICATIONS

SPECIFICATIONS - FRAME DIMENSIONS

NOTE: Frame dimensions are listed in metric scale.

VEHICLE PREPARATION

Position the vehicle on a level work surface. Verti-

cal dimensions can be taken from the work surface to

the locations indicated were applicable.

INDEX

DESCRIPTION FIGURE

FRAME DIMENSIONS 5
