DESCRIPTION N·m Ft. Lbs. In. Lbs.
Pedal Bracket to Firewall 23 — 204
Booster To Pedal Bracket 25 — 221
Brake Caliper Guide Pins
M8 Bolt
25 — 221
Brake Caliper Guide Pins
M10 Bolt
30 — 266
ALB Operating Linkage
Lever To The Rear Axle
34 25 300
Wheel Flange Ring To
Rotor
Rear
200 148 —
Wheel Flange Ring To
Rotor
Front
180 133 —
BASE BRAKE
NOTE: Do not resurface the disc brake rotors if
they are out of specifications. (Sprinter Van Rotors
must be replaced with new disc brake rotors only).
SPECIFICATIONS
DESCRIPTION SPECIFICATION
Front Disc Brake Caliper
Type
Dual Piston Sliding
Rear Disc Brake Caliper
Type
Single Piston Sliding
Disc Brake Caliper Bosch
Rear Disc Brake Rotor
New
DRW
22 mm (0.866 in.)
Rear Disc Brake Rotor
Wear Limit
DRW
19 mm (0.748 in.)
Rear Disc Brake Rotor
Max. Lateral Runout
DRW
.1 mm (0.0007 in.)
Rear Disc Brake Rotor
Max. Axial Runout
DRW
.02 mm (0.0039 in.)
Front Disc Brake Rotor
New
DRW
22 mm (0.866 in.)
Front Disc Brake Rotor
Wear Limit
DRW
19 mm (0.748 in.)
DESCRIPTION SPECIFICATION
Front Disc Brake Rotor
Max. Lateral Runout
DRW
0.05 mm (0.0019 in.)
Front Disc Brake Rotor
Max. Axial Runout
DRW
0.02 mm (0.0007 in.)
Front Disc Brake Rotor
New
SRW
22 mm (0.866 in.)
Front Disc Brake Rotor
Wear Limit
SRW
19 mm (0.748 in.)
Front Disc Brake Rotor
Max. Lateral Runout
SRW
0.05 mm (0.0019 in.)
Front Disc Brake Rotor
Max. Axial Runout
SRW
0.02 mm (0.0007 in.)
Rear Disc Brake Rotor
New
Models 901,902
12 mm (0.47 in.)
Rear Disc Brake Rotor
Wear Limit
Models 901,902
10 mm (0.40 in.)
Rear Disc Brake Rotor
Max. Lateral Runout
Models 901,902
.1 mm (0.0007 in.)
Rear Disc Brake Rotor
Max. Axial Runout
Models 901,902
0.02 mm (0.0007 in.)
5 - 6 BRAKES - BASE VA
HYDRAULIC/MECHANICAL (Continued)
