8W-30 FUEL/IGNITION SYSTEM
Component Page
Accelerator Pedal Position Sensor .......8W-30-8
Airbag Control Module ................8W-30-7
Automatic Temperature Control
Module ........................8W-30-2, 3
Boost Pressure Sensor ................8W-30-7
Boost Pressure Solenoid ...............8W-30-6
Camshaft Position Sensor .............8W-30-16
Central Timer Module ................8W-30-7
Controller Antilock Brake ............8W-30-2, 3
Crankcase Heater ...................8W-30-12
Crankshaft Position Sensor ...........8W-30-14
Data Link Connector ................8W-30-17
EGR Valve ........................8W-30-12
Engine Control Module . 8W-30-2, 3, 4, 5, 6, 7, 8, 9,
10, 11, 12, 13, 14, 15, 16, 17
Engine Control Relay ..............8W-30-12, 9
Engine Coolant Level Switch ..........8W-30-17
Engine Coolant Temperature Sensor ....8W-30-16
Engine Oil Sensor ...................8W-30-12
Fuel Injector No. 1 ..................8W-30-10
Fuel Injector No. 2 ..................8W-30-11
Fuel Injector No. 3 ..................8W-30-10
Fuel Injector No. 4 ..................8W-30-10
Fuel Injector No. 5 ..................8W-30-11
Fuel Level Sensor ...................8W-30-17
Fuel Pressure Sensor ................8W-30-15
Fuel Pressure Solenoid ...............8W-30-14
Fuel Shutdown Solenoid ..............8W-30-14
Fuel Temperature Sensor .............8W-30-15
Component Page
Fuse 5 ............................8W-30-5
Fuse 16............................8W-30-9
Fuse 17 ...........................8W-30-12
Fuse 18............................8W-30-7
Fuse Block No. 1 ................8W-30-7, 9, 12
G100 ...........................8W-30-5, 17
G200 ..............................8W-30-9
Glow Plug Control Module .............8W-30-5
Glow Plug No. 1 .....................8W-30-5
Glow Plug No. 2 .....................8W-30-5
Glow Plug No. 3 .....................8W-30-5
Glow Plug No. 4 .....................8W-30-5
Glow Plug No. 5 .....................8W-30-5
Instrument Cluster ..............8W-30-2, 3, 17
Intake Air Temperature Sensor .........8W-30-8
Kickdown Switch ....................8W-30-4
Low Fuel Pressure Sensor ............8W-30-13
Mass Air Flow Sensor .................8W-30-6
Power Distribution Center .............8W-30-5
Sensor ...........................8W-30-13
Sentry Key Remote Entry Module .....8W-30-2, 3
Shifter Assembly ..................8W-30-2, 3
Speed Control Switch .................8W-30-4
Starter Motor Relay .................8W-30-17
Transmission Control Module .........8W-30-2, 3
Water In Fuel Sensor ................8W-30-13
Wiper/Turn Signal/Engine Start Control
Module ..........................8W-30-9
VA 8W-30 FUEL/IGNITION SYSTEM 8W - 30 - 1
