POWER WINDOW MOTOR-DRIVER
CAV CIRCUIT FUNCTION
1 16BK DRIVER WINDOW DRIVER (UP)
2 16BL DRIVER WINDOW DRIVER (DOWN)
POWER WINDOW MOTOR-PASSENGER
CAV CIRCUIT FUNCTION
1 16BL PASSENGER WINDOW DRIVER (DOWN)
2 16BK PASSENGER WINDOW DRIVER (UP)
POWER WINDOW SWITCH-DRIVER
CAV CIRCUIT FUNCTION
1 16BL DRIVER WINDOW DRIVER (DOWN)
2 16BK DRIVER WINDOW DRIVER (UP)
3 16BR GROUND
4 16BK/YL FUSED OPTIONAL EQUIPMENT RELAY OUTPUT
5 16BR GROUND
POWER WINDOW SWITCH-MASTER
CAV CIRCUIT FUNCTION
1 16BL/WT MASTER PASSENGER WINDOW DRIVER (DOWN)
2 16BK/WT MASTER PASSENGER WINDOW DRIVER (UP)
3 16BR GROUND
4 16BK/YL/DG FUSED OPTIONAL EQUIPMENT RELAY OUTPUT
5 16BR GROUND
POWER WINDOW SWITCH-PASSENGER
CAV CIRCUIT FUNCTION
1 16BL PASSENGER WINDOW DRIVER (DOWN)
2 16BK PASSENGER WINDOW DRIVER (UP)
3 BL/WT MASTER PASSENGER WINDOW DRIVER (DOWN)
4 BK/YL/DG FUSED OPTIONAL EQUIPMENT RELAY OUTPUT
5 16BK/WT MASTER PASSENGER WINDOW DRIVER (UP)
8W - 80 - 54 8W-80 CONNECTOR PIN-OUTS VA
