MARKER LAMP-RIGHT REAR

CAV CIRCUIT FUNCTION

1 16GY/RD LAMP DRIVER

2 16BR GROUND

MASS AIR FLOW SENSOR - BLACK

CAV CIRCUIT FUNCTION

2 20YL/RD MASS AIR FLOW SENSOR 12 VOLT SUPPLY

3 20BR/YL SENSOR GROUND

4 20BR/BK MASS AIR FLOW SENSOR 5 VOLT SUPPLY

5 20YL/DG MASS AIR FLOW SENSOR SIGNAL

MASTER DOOR LOCK SWITCH

CAV CIRCUIT FUNCTION

1 16GY/DG/RD LAMP DRIVER

2 16WT/DG PASSENGER DOOR AJAR INDICATOR DRIVER

3 16WT/YL MASTER DOOR LOCK SWITCH SENSE-ALL DOORS

8 16WT/RD MASTER DOOR LOCK SWITCH SENSE-PASSENGER

DOORS

9 16WT/BK DRIVER DOOR AJAR INDICATOR DRIVER

10 16BR GROUND

METERING PUMP

CAV CIRCUIT FUNCTION

1 16DG/RD METERING PUMP DRIVER

2 16BR METERING PUMP GROUND

MICROPHONE CONNECTOR

CAV CIRCUIT FUNCTION

1 18BR MICROPHONE CONNECOTR CAV 1 TO CTEL CON-

NECTOR CAV 9

2 18BL MICROPHONE CONNECOTR CAV 2 TO CTEL CON-

NECTOR CAV 18
