8W-97 POWER DISTRIBUTION
TABLE OF CONTENTS
page page
POWER DISTRIBUTION
DESCRIPTION ..........................1
OPERATION ............................1
CIGAR LIGHTER OUTLET
DESCRIPTION ..........................1
OPERATION ............................2
DIAGNOSIS AND TESTING - CIGAR LIGHTER
OUTLET .............................2
REMOVAL .............................2
CIRCUIT BREAKER
DESCRIPTION ..........................2
OPERATION ............................2
DIAGNOSIS AND TESTING - CIRCUIT
BREAKER ............................2
FUSE BLOCK #1
DESCRIPTION ..........................2
OPERATION ............................2
REMOVAL .............................3
INSTALLATION ..........................3
FUSE BLOCK #2
DESCRIPTION ..........................3
OPERATION ............................3
POWER DISTRIBUTION CENTER
DESCRIPTION ..........................3
OPERATION ............................3
POWER OUTLET
DESCRIPTION ..........................3
OPERATION ............................4
DIAGNOSIS AND TESTING - POWER OUTLET . 4
REMOVAL .............................4
INSTALLATION ..........................4
RELAY
DESCRIPTION ..........................4
OPERATION ............................5
DIAGNOSIS AND TESTING - RELAY .........5
REMOVAL .............................5
INSTALLATION ..........................5
POWER DISTRIBUTION
DESCRIPTION
This section describes the power distribution com-
ponents used on this model as well as the methods in
which battery voltage and charging system voltage is
distributed throughout the vehicle. The power distri-
bution system for this vehicle consists of the follow-
ing major components which are covered in further
detail later in this section:
• Fuseblock #1
• Fuseblock #2
• Power Distribution Center (PDC)
The power distribution system also incorporates
various types of circuit control and protection fea-
tures, including:
• Automatic resetting circuit breakers
• Blade-type fuses
• Cartridge fuses
• Relays
Following are general descriptions and theory of
operation for the major components in the power dis-
tribution system. Refer to Wiring for the location of
complete circuit diagrams for the various power dis-
tribution system components.
OPERATION
The power distribution system for this vehicle is
designed to provide safe, reliable, and centralized dis-
tribution points for the electrical current required to
operate all of the standard and optional factory-in-
stalled electrical and powertrain, chassis, safety,
security and convenience systems. At the same time,
the power distribution system was designed to pro-
vide easy access to these electrical distribution points
for the vehicle technician to use when conducting
diagnosis and repair of faulty circuits. The power dis-
tribution system can also prove useful for the addi-
tion of electrical circuits that may be required to
operate accessories that the vehicle owner may
choose to have installed in the aftermarket.
CIGAR LIGHTER OUTLET
DESCRIPTION
The cigar lighter outlet is installed in the instru-
ment panel, near the center of the instrument panel.
The cigar lighter outlet is secured by a snap fit
within the instrument panel.
The cigar lighter knob/heating element, and the
cigar lighter outlet are available for service. These
components cannot be repaired and, if faulty or dam-
aged, they must be replaced.
VA 8W-97 POWER DISTRIBUTION 8W - 97 - 1
